Suspension polymerization (PVC)

Suspension polymerization (PVC)

PVC is one of the most commonly used polymers worldwide and has outstanding properties, mainly due to its ability to absorb additives such as plasticizers. In the polymerisation process, Celopro® controls the particle size and porosity which is decisive for its additive absorbing behaviour.

An important characteristic of polyvinylchloride (PVC) is its ability to absorb additives, such as plasticizers, stabilizers, pigments, and impact modifiers, quickly and in sufficient quantities. However, the required porosity level is often obtained at the expense of bulk density. Using the appropriate suspending agent during polymerization allows the producer to maintain a balance of these properties.

Recommended Solutions

Hydroxypropyl methyl cellulose(HPMC)

HPMC has excellent dispersing and stabilizing properties, and can adjust the particle size distribution and porosity of PVC resin. It is an important additive in PVC suspension polymerization reaction. Recommend grade: Celopro®VF, Celopro®VXF, Celopro®VE, Celopro®VXE



Why Celopro®

Celopro cellulose ethers have been used as suspending agents for vinyl chloride polymerization. These products are protective colloids made of linear polymers of condensed anhydroglucose rings that form a carbohydrate skeleton. Methyl and hydroxypropyl groups are attached to the carbohydrate skeleton via an ether linkage. Celopro cellulose ethers are nonionic, surface-active film formers.

When used as suspending agents in vinyl chloride polymerization, they provide particle size control, uniform particle size distribution, and porosity that can be optimized for many PVC end-uses. This publication discusses the use of Celopro cellulose ethers as suspending agents for vinyl chloride polymerization.

Product Features and Advantages

1. Good Dispersibility

In suspension polymerization, Celopro®cellulose ether acts as a dispersant to prevent the aggregation between early polymerization droplets and between mid- and late-stage polymer particles.

2. Good Stability

During the polymerization reaction, Celopro®cellulose ether can be adsorbed on the surface of vinyl chloride monomer droplets to form a protective film, thereby affecting the morphology of the final product.

3. Reduce interfacial tension

Celopro®cellulose ethercan reduce the interfacial tension between droplets and water and promote the dispersion of droplets, which is very important for controlling the size and morphology of PVC particles.

4. Improve plasticization performance

Celopro®Cellulose ether can affect the particle sizeand its distribution, porosity and other characteristics of resin particles. The PVC produced is easy to absorb plasticizers and plasticize.

Recommended Products

Typical Properties of Celopro® Cellulose Ethers

ProductMeO (%)HPO (%)Viscosity (mPas)NaCl (%)Fe (ppm)H2O (%)
Celopro®VF22-236-780 – 120<2.0<150<5.0
Celopro®VXF28-296-740 – 60<1.5<150<5.0
Celopro®VXE29-3011-1245 – 55<1.5<150<5.0

Solution Properties of Celopro® Cellulose Ethers

ProductGel Temp.Extractable Cellulose Ethera (%)IFTb (dyne/cm)Viscosityc (mPas)Application
Celopro®VF720.4215.6100Rigid PVC, low porosity, high bulk density
Celopro®VXF671.5811.250General purpose suspending agent
Celopro®VXE602.468.650Flexible PVC, high porosity, low VCM residuals
Celopro®VE623.27.515Flexible PVC, high porosity, low VCM residuals





Our Service

“Celotech Offers the Right Product”

Celotech laboratory conduct a large number of comparative tests and experiments every day to ensure that the most suitable and high-quality cellulose ether dispersants are provided for the polymerization industry. We have professional technicians who have been engaged in the chemical industry for more than 20 years, ensuring that every one of your needs can be responded to promptly and accurately.

“Celotech’s Excellent After-Sale Service”

Perhaps you have met some suppliers who ignore or shirk responsibility when faced with your complaints or . However, Celotech always puts customers first, responds to customer needs in time, and could sends professional technicians to solve complex problems for customers face to face, allowing customers to experience the most comfortable service. Before shipment, the laboratory will take and keep samples from each batch to eliminate the possibility of quality problems and to trace customer complaints timely.

“Celotech’s Professional Packaging and Logistics Services”

Celotech provides professional packaging services, accurately calculates the maximum loading quantity to save the logistic costs for customers and we ensure the safety and integrity of your cellulose ether products during transportation. We can also provide customized packaging solutions, providing neutral packaging or OEM packaging.

We have established long-term cooperation with many well-known logistics companies to provide the most cost-effective transportation solutions whether it is air, sea or land transportation.

Related Posts

Carboxymethyl cellulose (CMC) is a cornerstone of modern industrial and consumer products, offering unparalleled versatility and performance.
The cellulose ether is a polymer compound having an ether structure made of cellulose, and each glucosyl ring in the cellulose macromolecule contains three hydroxyl groups, a primary hydroxyl group on the sixth carbon atom, and a second or three carbon atoms.

Frequently Asked Questions

Our Celotech Application Lab usually prepares free samples weighing less than 1.0kg, but the freight delivery fees from my lab to consignee should be on consignee’s account.

Always a pre-production sample for customer’s checking before mass production; Always final Inspection before shipment.
